Boiler Wall Tubes Circa 1970s

Section of boiler wall from Clover Bar

Saturday, August 09, 2014

Section of furnace wall tubes this type is known as a

 membrane wall as the furnace is pressurized



Manufacturer              Babcock and Wilcox

Specifications:                          Radiant Boiler

Heating Surface:                         79,778 sq.ft.

Pressure                   2100 psi

ADD PHOTO??

Section of CB No. 4 boiler wall being cut out 2007 Jan 19



Categories: Boilers Collection
Tags: Clover Bar

Author: ephf
